090060RVS

The function of tube clamps is the fixing of straight tubes, bent tubes and hoses. Their notable features are re-set capability, high tensile strength, very high abrasion resistance and excellent resistance to cold.

Programme:

Ermeto Series A tube clamps (according to DIN 3015 Part 1) are available in seven standard sizes for normal mechanical requirements. The clamp body is available in a round/closed version.

Other elements are welding plates, rail supports, cover plates and construction types.

Ermeto Series B tube clamps (according to DIN 3015 Part 3) are available as a twin tube clamp in five standard sizes for normal mechanical requirements. The clamp body is available in a square/open design. Other components are welding plates, rail supports, cover plates and construction types. Clamp halves with different diameters are only possible when used together.

Ermeto Series C tube clamps (according to DIN 3015 Part 2) are specially designed for high mechanical requirements and are available in eight standard sizes. The clamp body is available in a square/closed design. Other components are welding plates, rail supports, cover plates and construction types. The design is according to DIN 3015 - both upper and lower clamp-halves are identical. Webs inside the bores of the clamps provide an impact and vibration-deadening effect and absorb the forces towards the direction of the tube axis. When using hoses and cables, Parker recommends the use of clamp halves with a smooth bore.

Technical specifications:

Ermeto Series A:

The outside tube diameters for the metric series are from 6 to 57 mm.
The outside tube diameters for the inch-size series R are from 1/8˝ to R 1.˝
The outside tube diameters for the imperial size series are from 1/4 to 2 1/2˝.

Ermeto Series B:

The outside tube diameters are from 6 to 42 mm.

Ermeto Series C:

The outside tube diameters are from 6 to 220 mm.

Clamp material:

Polypropylene –30°C up to +90°C, colour dark green
Polyamide –40°C up to +120°C, colour black
Rubber –50°C up to +120°C, colour black
Aluminium up to +300°C
All metal parts are also available in stainless steel. Other materials upon request.
Stainless steel qualitities are to 1.4401/1.4571 (AISI 316/316 Ti), resistant to rust and acid.

Markets:

• Automotive
• Defence
• Energy
• Environment
• Industrial
• Infrastructure
• Machine Tools
• Materials Handling
• Mobile
• Oil and Gas
• Power Generation
• Process
• Transportation
• Water

Applications:

• Suitable for general hydraulic applications.

Features/ Benefits of EO tube clamps:

• The function of tube clamps is the fixing of straight tubes, bent tubes and hoses, the broad product range of Parker tube clamps helps to find a solution for all requests and therefore extends the range of applications.
• Their notable features are re-set capability, high tensile strength, very high abrasion resistance and excellent resistance to cold. This range of features enlarges the number of possible applications and stretches the life-cycle of tube clamps.
