C0D300-40S

COD and COP

Thrust cylinders

The thrust cylinders are linear actuators, designed for a high force to size ratio. This makes the cylinder ideal to use for clamping, riveting, punching and similar applications where a high force is required. The range includes 14 different versions, providing forces from 1600 to 25 000 N (at 6 bar), single? as well as double? acting and in piston or diaphragm design. nThe single?acting version has a built in powerful spring for the return stroke, but for applications where a high force is required in both directions there is the double?acting version. The cylinder body is an all zinc plated sheet of steel and the piston rod, which is guided in two maintenance free bearings, is provided with flats and a male thread. To facilitate the installation, the guiding sleeve is provided with a thread which can be used either for direct mounting in na threaded hole or for installation in a free running hole using a lock nut.
